ProPhotonix has more than 25 years of experience as a supplier and integrator of laser diode technology.
Find the laser diode you need – select from one of the following tabs:
Laser Diodes:
With 25 years of experience in laser diodes, ProPhotonix offers:
- Expert Technical Support to help you to get the most from your application
- A wide range of laser diodes in stock for immediate shipment
- Excellent value due to strong relationships with laser diode manufacturers
- Advice on other elements of your system – optics, drive electronics or laser modules
| Part Number | Wavelength (nm) | Power (mW) | Package (mm) | Max Operating Temp (°C) | Pin Configuration | Manufacturer | Download datasheet |
|---|---|---|---|---|---|---|---|
| moreHL37013MG
Wavelength (nm): 375 Power (mW): 200 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 30 |
375 | 200 | 5.6 | 30 | LD Only | Ushio | file link |
| moreHL40041MG
Wavelength (nm): 404 Power (mW): 150 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 50 |
404 | 150 | 5.6 | 50 | 3P | Ushio | file link |
| moreHL40053MG
Wavelength (nm): 404 Power (mW): 400 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 30 |
404 | 400 | 5.6 | 30 | LD Only | Ushio | file link |
| moreCP-405-PLR12
Wavelength (nm): 405 Power (mW): 12 Package (mm): 9 Manufacturer: Ondax Pin Configuration: LD Only Max Operating Temp (°C): 60 |
405 | 12 | 9 | 60 | LD Only | Ondax | file link |
| moreCP-406-PLR12
Wavelength (nm): 405 Power (mW): 12 Package (mm): 9 Manufacturer: Ondax Pin Configuration: LD Only Max Operating Temp (°C): 60 |
405 | 12 | 9 | 60 | LD Only | Ondax | file link |
| moreCP-40X-PLR12
Wavelength (nm): 405 Power (mW): 12 Package (mm): 9 Manufacturer: Ondax Pin Configuration: LD Only Max Operating Temp (°C): 60 |
405 | 12 | 9 | 60 | LD Only | Ondax | file link |
| moreCP-40X-PLR25
Wavelength (nm): 405 Power (mW): 25 Package (mm): 9 Manufacturer: Ondax Pin Configuration: LD Only Max Operating Temp (°C): 60 |
405 | 25 | 9 | 60 | LD Only | Ondax | file link |
| moreCP-405-PLR40
Wavelength (nm): 405 Power (mW): 40 Package (mm): 9 Manufacturer: Ondax Pin Configuration: LD Only Max Operating Temp (°C): 60 |
405 | 40 | 9 | 60 | LD Only | Ondax | file link |
| moreCP-406-PLR40
Wavelength (nm): 405 Power (mW): 40 Package (mm): 9 Manufacturer: Ondax Pin Configuration: LD Only Max Operating Temp (°C): 60 |
405 | 40 | 9 | 60 | LD Only | Ondax | file link |
| moreCP-40X-PLR40
Wavelength (nm): 405 Power (mW): 40 Package (mm): 9 Manufacturer: Ondax Pin Configuration: LD Only Max Operating Temp (°C): 60 |
405 | 40 | 9 | 60 | LD Only | Ondax | file link |
| moreHL40161MG/163MG
Wavelength (nm): 405 Power (mW): 175 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 85 |
405 | 175 | 5.6 | 85 | 3P | Ushio | file link |
| moreHL40071MG
Wavelength (nm): 405 Power (mW): 300 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 70 |
405 | 300 | 5.6 | 70 | LD Only | Ushio | file link |
| moreHL40063MG
Wavelength (nm): 405 Power (mW): 600 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 30 |
405 | 600 | 5.6 | 30 | LD Only | Ushio | file link |
| moreHL40065MG
Wavelength (nm): 405 Power (mW): 600 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 2M Max Operating Temp (°C): 30 |
405 | 600 | 5.6 | 30 | 2M | Ushio | file link |
| moreHL40173MG/175MG
Wavelength (nm): 405 Power (mW): 600 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 30 |
405 | 600 | 5.6 | 30 | 3P | Ushio | file link |
| moreHL40033G
Wavelength (nm): 405 Power (mW): 1000 Package (mm): 9 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 30 |
405 | 1000 | 9 | 30 | LD Only | Ushio | file link |
| moreHL40085G
Wavelength (nm): 405 Power (mW): 1000 Package (mm): 9 Manufacturer: Ushio Pin Configuration: 2M Max Operating Temp (°C): 30 |
405 | 1000 | 9 | 30 | 2M | Ushio | file link |
| moreHL40103HD
Wavelength (nm): 405 Power (mW): 3500 Package (mm): 9 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 30 |
405 | 3500 | 9 | 30 | LD Only | Ushio | file link |
| morePLT5-450B
Wavelength (nm): 450 Power (mW): 80 Package (mm): 5.6 Manufacturer: Osram Pin Configuration: LD Only Max Operating Temp (°C): 70 |
450 | 80 | 5.6 | 70 | LD Only | Osram | file link |
| morePLPT9-450D-E-A01
Wavelength (nm): 450 Power (mW): 100 Package (mm): 5.6 Manufacturer: Osram Pin Configuration: LD Only Max Operating Temp (°C): 105 |
450 | 100 | 5.6 | 105 | LD Only | Osram | file link |
| morePL450B
Wavelength (nm): 450 Power (mW): 120 Package (mm): 3.8 Manufacturer: Osram Pin Configuration: LD Only Max Operating Temp (°C): 70 |
450 | 120 | 3.8 | 70 | LD Only | Osram | file link |
| morePLPT9-450LA-E
Wavelength (nm): 450 Power (mW): 3000 Package (mm): 9 Manufacturer: Osram Pin Configuration: LD Only Max Operating Temp (°C): 85 |
450 | 3000 | 9 | 85 | LD Only | Osram | file link |
| morePLT5-488
Wavelength (nm): 488 Power (mW): 60 Package (mm): 5.6 Manufacturer: Osram Pin Configuration: 3 PIN Max Operating Temp (°C): 60 |
488 | 60 | 5.6 | 60 | 3 PIN | Osram | file link |
| morePLT5-488-C1C6
Wavelength (nm): 488 Power (mW): 60 Package (mm): 5.6 Manufacturer: Osram Pin Configuration: 3 PIN Max Operating Temp (°C): 60 |
488 | 60 | 5.6 | 60 | 3 PIN | Osram | file link |
| morePLT5-510-E9600
Wavelength (nm): 515 Power (mW): 10 Package (mm): 5.6 Manufacturer: Osram Pin Configuration: LD Only Max Operating Temp (°C): 60 |
515 | 10 | 5.6 | 60 | LD Only | Osram | file link |
| morePLT5 520DB_P
Wavelength (nm): 515 Power (mW): 10 Package (mm): 5.6 Manufacturer: Osram Pin Configuration: 3 PIN Max Operating Temp (°C): 60 |
515 | 10 | 5.6 | 60 | 3 PIN | Osram | file link |
| morePLT3-510
Wavelength (nm): 520 Power (mW): 10 Package (mm): 3.8 Manufacturer: Osram Pin Configuration: LD Only Max Operating Temp (°C): 60 |
520 | 10 | 3.8 | 60 | LD Only | Osram | file link |
| morePLT5 520EB_P
Wavelength (nm): 520 Power (mW): 20 Package (mm): 5.6 Manufacturer: Osram Pin Configuration: 3 PIN Max Operating Temp (°C): 60 |
520 | 20 | 5.6 | 60 | 3 PIN | Osram | file link |
| morePLT5 520EB_Q
Wavelength (nm): 520 Power (mW): 20 Package (mm): 5.6 Manufacturer: Osram Pin Configuration: 3 PIN Max Operating Temp (°C): 70 |
520 | 20 | 5.6 | 70 | 3 PIN | Osram | file link |
| morePLT5-520-B4-5-6
Wavelength (nm): 520 Power (mW): 30 Package (mm): 5.6 Manufacturer: Osram Pin Configuration: 2M Max Operating Temp (°C): 60 |
520 | 30 | 5.6 | 60 | 2M | Osram | file link |
| morePLT5 518FB_P
Wavelength (nm): 520 Power (mW): 30 Package (mm): 5.6 Manufacturer: Osram Pin Configuration: 3 PIN Max Operating Temp (°C): 60 |
520 | 30 | 5.6 | 60 | 3 PIN | Osram | file link |
| morePLT5-520 -B1-2-3
Wavelength (nm): 520 Power (mW): 50 Package (mm): 5.6 Manufacturer: Osram Pin Configuration: 2M Max Operating Temp (°C): 60 |
520 | 50 | 5.6 | 60 | 2M | Osram | file link |
| morePLT3 520FB
Wavelength (nm): 520 Power (mW): 50 Package (mm): 3.8 Manufacturer: Osram Pin Configuration: 3 PIN Max Operating Temp (°C): 60 |
520 | 50 | 3.8 | 60 | 3 PIN | Osram | file link |
| morePLT5 520FB_P
Wavelength (nm): 520 Power (mW): 50 Package (mm): 5.6 Manufacturer: Osram Pin Configuration: 3 PIN Max Operating Temp (°C): 60 |
520 | 50 | 5.6 | 60 | 3 PIN | Osram | file link |
| morePL520B
Wavelength (nm): 520 Power (mW): 80 Package (mm): 5.6 Manufacturer: Osram Pin Configuration: LD Only Max Operating Temp (°C): 60 |
520 | 80 | 5.6 | 60 | LD Only | Osram | file link |
| morePLT5-520B
Wavelength (nm): 520 Power (mW): 80 Package (mm): 5.6 Manufacturer: Osram Pin Configuration: 2M Max Operating Temp (°C): 60 |
520 | 80 | 5.6 | 60 | 2M | Osram | file link |
| morePLT3-520D
Wavelength (nm): 520 Power (mW): 140 Package (mm): 3.8 Manufacturer: Osram Pin Configuration: LD Only Max Operating Temp (°C): 60 |
520 | 140 | 3.8 | 60 | LD Only | Osram | file link |
| moreHL63163DG
Wavelength (nm): 633 Power (mW): 100 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 40 |
633 | 100 | 5.6 | 40 | LD Only | Ushio | file link |
| moreQL63D4SA
Wavelength (nm): 635 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 40 |
635 | 5 | 5.6 | 40 | 1N | QSI | file link |
| moreQL63D4SB
Wavelength (nm): 635 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 40 |
635 | 5 | 5.6 | 40 | 2M | QSI | file link |
| moreQL63D4SC
Wavelength (nm): 635 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 40 |
635 | 5 | 5.6 | 40 | 3P | QSI | file link |
| moreQL63D43A
Wavelength (nm): 635 Power (mW): 5 Package (mm): 3.3 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 40 |
635 | 5 | 3.3 | 40 | 1N | QSI | file link |
| moreQL63D43B
Wavelength (nm): 635 Power (mW): 5 Package (mm): 3.3 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 40 |
635 | 5 | 3.3 | 40 | 2M | QSI | file link |
| moreHL6312G-A
Wavelength (nm): 635 Power (mW): 5 Package (mm): 9 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 50 |
635 | 5 | 9 | 50 | 1N | Ushio | file link |
| moreQL63D5SA
Wavelength (nm): 635 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 50 |
635 | 5 | 5.6 | 50 | 1N | QSI | file link |
| moreQL63D5SB
Wavelength (nm): 635 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 50 |
635 | 5 | 5.6 | 50 | 2M | QSI | file link |
| moreQL63D5SC
Wavelength (nm): 635 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 50 |
635 | 5 | 5.6 | 50 | 3P | QSI | file link |
| moreHL6354MG-A
Wavelength (nm): 635 Power (mW): 7 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 50 |
635 | 7 | 5.6 | 50 | 1N | Ushio | file link |
| moreHL6355MG-A
Wavelength (nm): 635 Power (mW): 7 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 50 |
635 | 7 | 5.6 | 50 | 3P | Ushio | file link |
| moreHL6319G-A
Wavelength (nm): 635 Power (mW): 10 Package (mm): 9 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 50 |
635 | 10 | 9 | 50 | 3P | Ushio | file link |
| moreHL6320G-A
Wavelength (nm): 635 Power (mW): 10 Package (mm): 9 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 50 |
635 | 10 | 9 | 50 | 1N | Ushio | file link |
| moreQL63F5SA
Wavelength (nm): 635 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 50 |
635 | 10 | 5.6 | 50 | 1N | QSI | file link |
| moreQL63F5SB
Wavelength (nm): 635 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 50 |
635 | 10 | 5.6 | 50 | 2M | QSI | file link |
| moreQL63F5SC
Wavelength (nm): 635 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 50 |
635 | 10 | 5.6 | 50 | 3P | QSI | file link |
| moreQL63F7SA
Wavelength (nm): 635 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 70 |
635 | 10 | 5.6 | 70 | 1N | QSI | file link |
| moreQL63F7SB
Wavelength (nm): 635 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 70 |
635 | 10 | 5.6 | 70 | 2M | QSI | file link |
| moreQL63F7SC
Wavelength (nm): 635 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 70 |
635 | 10 | 5.6 | 70 | 3P | QSI | file link |
| moreHL6321G-A
Wavelength (nm): 635 Power (mW): 15 Package (mm): 9 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 50 |
635 | 15 | 9 | 50 | 3P | Ushio | file link |
| moreHL6322G-A
Wavelength (nm): 635 Power (mW): 15 Package (mm): 9 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 50 |
635 | 15 | 9 | 50 | 1N | Ushio | file link |
| moreQL63G5SA
Wavelength (nm): 635 Power (mW): 15 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 50 |
635 | 15 | 5.6 | 50 | 1N | QSI | file link |
| moreQL63G5SB
Wavelength (nm): 635 Power (mW): 15 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 50 |
635 | 15 | 5.6 | 50 | 2M | QSI | file link |
| moreQL63G5SC
Wavelength (nm): 635 Power (mW): 15 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 50 |
635 | 15 | 5.6 | 50 | 3P | QSI | file link |
| moreQL63G5SA-L
Wavelength (nm): 635 Power (mW): 15 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 65 |
635 | 15 | 5.6 | 65 | 1N | QSI | file link |
| moreQL63G5SB-L
Wavelength (nm): 635 Power (mW): 15 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 65 |
635 | 15 | 5.6 | 65 | 2M | QSI | file link |
| moreQL63G5SC-L
Wavelength (nm): 635 Power (mW): 15 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 65 |
635 | 15 | 5.6 | 65 | 3P | QSI | file link |
| moreQL63H5SA
Wavelength (nm): 635 Power (mW): 20 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 50 |
635 | 20 | 5.6 | 50 | 1N | QSI | file link |
| moreQL63H5SB
Wavelength (nm): 635 Power (mW): 20 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 50 |
635 | 20 | 5.6 | 50 | 2M | QSI | file link |
| moreQL63H5SC
Wavelength (nm): 635 Power (mW): 20 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 50 |
635 | 20 | 5.6 | 50 | 3P | QSI | file link |
| moreHL6323MG-A
Wavelength (nm): 635 Power (mW): 35 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 50 |
635 | 35 | 5.6 | 50 | 1N | Ushio | file link |
| moreTO-636-PLR09
Wavelength (nm): 636 Power (mW): 9 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 1N Max Operating Temp (°C): 40 |
636 | 9 | 5.6 | 40 | 1N | Ondax | file link |
| moreHL63101MG-A
Wavelength (nm): 637 Power (mW): 7 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 60 |
637 | 7 | 5.6 | 60 | 3P | Ushio | file link |
| moreHL63102MG-A
Wavelength (nm): 637 Power (mW): 7 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 60 |
637 | 7 | 5.6 | 60 | 1N | Ushio | file link |
| moreHL63142DG
Wavelength (nm): 637 Power (mW): 120 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 50 |
637 | 120 | 5.6 | 50 | 1N | Ushio | file link |
| moreTO-638-PLR09
Wavelength (nm): 638 Power (mW): 9 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 1N Max Operating Temp (°C): 40 |
638 | 9 | 5.6 | 40 | 1N | Ondax | file link |
| moreTO-638-PLR20
Wavelength (nm): 638 Power (mW): 20 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 2M Max Operating Temp (°C): 50 |
638 | 20 | 5.6 | 50 | 2M | Ondax | file link |
| moreTO-638-PLR32
Wavelength (nm): 638 Power (mW): 32 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 3P Max Operating Temp (°C): 50 |
638 | 32 | 5.6 | 50 | 3P | Ondax | file link |
| moreHL63603TG
Wavelength (nm): 638 Power (mW): 110 Package (mm): 3.8 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 60 |
638 | 110 | 3.8 | 60 | LD Only | Ushio | file link |
| moreHL63153AT
Wavelength (nm): 638 Power (mW): 150 Package (mm): 3.8 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 60 |
638 | 150 | 3.8 | 60 | LD Only | Ushio | file link |
| moreHL63133DG
Wavelength (nm): 638 Power (mW): 170 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 40 |
638 | 170 | 5.6 | 40 | LD Only | Ushio | file link |
| moreHL63263DG
Wavelength (nm): 638 Power (mW): 200 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 40 |
638 | 200 | 5.6 | 40 | LD Only | Ushio | file link |
| moreHL63391DG
Wavelength (nm): 638 Power (mW): 200 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 60 |
638 | 200 | 5.6 | 60 | 3P | Ushio | file link |
| moreHL63392DG
Wavelength (nm): 638 Power (mW): 200 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 60 |
638 | 200 | 5.6 | 60 | 1N | Ushio | file link |
| moreHL63253MG
Wavelength (nm): 638 Power (mW): 450 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 40 |
638 | 450 | 5.6 | 40 | LD Only | Ushio | file link |
| moreHL63193MG
Wavelength (nm): 638 Power (mW): 700 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 40 |
638 | 700 | 5.6 | 40 | LD Only | Ushio | file link |
| moreHL63283HD
Wavelength (nm): 638 Power (mW): 1200 Package (mm): 9 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 45 |
638 | 1200 | 9 | 45 | LD Only | Ushio | file link |
| moreHL63290HD
Wavelength (nm): 638 Power (mW): 2200 Package (mm): 9 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 45 |
638 | 2200 | 9 | 45 | LD Only | Ushio | file link |
| moreHL63520HD
Wavelength (nm): 638 Power (mW): 2400 Package (mm): 9 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 55 |
638 | 2400 | 9 | 55 | LD Only | Ushio | file link |
| moreHL6395MG-A
Wavelength (nm): 639 Power (mW): 10 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 60 |
639 | 10 | 5.6 | 60 | 3P | Ushio | file link |
| moreHL6396MG-A
Wavelength (nm): 639 Power (mW): 10 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 60 |
639 | 10 | 5.6 | 60 | 1N | Ushio | file link |
| moreHL6358MG-A
Wavelength (nm): 639 Power (mW): 12 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 50 |
639 | 12 | 5.6 | 50 | 1N | Ushio | file link |
| moreHL6359MG-A
Wavelength (nm): 639 Power (mW): 12 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 50 |
639 | 12 | 5.6 | 50 | 3P | Ushio | file link |
| moreHL6360MG-A
Wavelength (nm): 639 Power (mW): 25 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 50 |
639 | 25 | 5.6 | 50 | 1N | Ushio | file link |
| moreHL6361MG-A
Wavelength (nm): 639 Power (mW): 25 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 50 |
639 | 25 | 5.6 | 50 | 3P | Ushio | file link |
| moreHL6397MG-A
Wavelength (nm): 639 Power (mW): 25 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 60 |
639 | 25 | 5.6 | 60 | 3P | Ushio | file link |
| moreHL6398MG-A
Wavelength (nm): 639 Power (mW): 25 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 60 |
639 | 25 | 5.6 | 60 | 1N | Ushio | file link |
| moreHL63643DG
Wavelength (nm): 639 Power (mW): 210 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 60 |
639 | 210 | 5.6 | 60 | LD Only | Ushio | file link |
| moreHL63641DG
Wavelength (nm): 639 Power (mW): 210 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 60 |
639 | 210 | 5.6 | 60 | LD Only | Ushio | file link |
| moreHL63642DG
Wavelength (nm): 639 Power (mW): 210 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 60 |
639 | 210 | 5.6 | 60 | 1N | Ushio | file link |
| moreTO-640-PLR09
Wavelength (nm): 640 Power (mW): 9 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 1N Max Operating Temp (°C): 40 |
640 | 9 | 5.6 | 40 | 1N | Ondax | file link |
| moreTO-640-PLR20
Wavelength (nm): 640 Power (mW): 20 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 3P Max Operating Temp (°C): 50 |
640 | 20 | 5.6 | 50 | 3P | Ondax | file link |
| moreTO-640-PLR32
Wavelength (nm): 640 Power (mW): 32 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 3P Max Operating Temp (°C): 50 |
640 | 32 | 5.6 | 50 | 3P | Ondax | file link |
| moreHL6362MG-A
Wavelength (nm): 640 Power (mW): 45 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 50 |
640 | 45 | 5.6 | 50 | 1N | Ushio | file link |
| moreHL6363MG-A
Wavelength (nm): 640 Power (mW): 45 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 50 |
640 | 45 | 5.6 | 50 | 3P | Ushio | file link |
| moreHL63653TG
Wavelength (nm): 640 Power (mW): 210 Package (mm): 3.8 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 60 |
640 | 210 | 3.8 | 60 | 3P | Ushio | file link |
| moreHL6388MG
Wavelength (nm): 640 Power (mW): 250 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 50 |
640 | 250 | 5.6 | 50 | LD Only | Ushio | file link |
| moreHL6364DG-A
Wavelength (nm): 642 Power (mW): 65 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 50 |
642 | 65 | 5.6 | 50 | 1N | Ushio | file link |
| moreHL6365DG-A
Wavelength (nm): 642 Power (mW): 65 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 50 |
642 | 65 | 5.6 | 50 | 3P | Ushio | file link |
| moreHL6366DG-A
Wavelength (nm): 642 Power (mW): 90 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 50 |
642 | 90 | 5.6 | 50 | 1N | Ushio | file link |
| moreHL6367DG-A
Wavelength (nm): 642 Power (mW): 90 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 50 |
642 | 90 | 5.6 | 50 | 3P | Ushio | file link |
| moreHL6385DG-A
Wavelength (nm): 642 Power (mW): 150 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 40 |
642 | 150 | 5.6 | 40 | LD Only | Ushio | file link |
| moreQL65D53A
Wavelength (nm): 650 Power (mW): 5 Package (mm): 3.3 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 50 |
650 | 5 | 3.3 | 50 | 1N | QSI | file link |
| moreQL65D53B
Wavelength (nm): 650 Power (mW): 5 Package (mm): 3.3 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 50 |
650 | 5 | 3.3 | 50 | 2M | QSI | file link |
| moreQL65D6SA
Wavelength (nm): 650 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 60 |
650 | 5 | 5.6 | 60 | 1N | QSI | file link |
| moreQL65D6SB
Wavelength (nm): 650 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 60 |
650 | 5 | 5.6 | 60 | 2M | QSI | file link |
| moreQL65D6SC
Wavelength (nm): 650 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 60 |
650 | 5 | 5.6 | 60 | 3P | QSI | file link |
| moreQL65D7SA
Wavelength (nm): 650 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 70 |
650 | 5 | 5.6 | 70 | 1N | QSI | file link |
| moreQL65D7SB
Wavelength (nm): 650 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 70 |
650 | 5 | 5.6 | 70 | 2M | QSI | file link |
| moreQL65D7SC
Wavelength (nm): 650 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 70 |
650 | 5 | 5.6 | 70 | 3P | QSI | file link |
| moreQL65D7SA-L
Wavelength (nm): 650 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 70 |
650 | 5 | 5.6 | 70 | 1N | QSI | file link |
| moreQL65D7SB-L
Wavelength (nm): 650 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 70 |
650 | 5 | 5.6 | 70 | 2M | QSI | file link |
| moreQL65D7SC-L
Wavelength (nm): 650 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 70 |
650 | 5 | 5.6 | 70 | 3P | QSI | file link |
| moreQL65D7SA-PS
Wavelength (nm): 650 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 70 |
650 | 5 | 5.6 | 70 | 1N | QSI | file link |
| moreQL65D7SB-PS
Wavelength (nm): 650 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 70 |
650 | 5 | 5.6 | 70 | 1N | QSI | file link |
| moreQL65D7SC-PS
Wavelength (nm): 650 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 70 |
650 | 5 | 5.6 | 70 | 3P | QSI | file link |
| moreQL65E8SA
Wavelength (nm): 650 Power (mW): 7 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 85 |
650 | 7 | 5.6 | 85 | 1N | QSI | file link |
| moreQL65E8SB
Wavelength (nm): 650 Power (mW): 7 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 85 |
650 | 7 | 5.6 | 85 | 2M | QSI | file link |
| moreQL65E8SC
Wavelength (nm): 650 Power (mW): 7 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 85 |
650 | 7 | 5.6 | 85 | 3P | QSI | file link |
| moreQL65F6SA
Wavelength (nm): 650 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 60 |
650 | 10 | 5.6 | 60 | 1N | QSI | file link |
| moreQL65F6SB
Wavelength (nm): 650 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 60 |
650 | 10 | 5.6 | 60 | 2M | QSI | file link |
| moreQL65F6SC
Wavelength (nm): 650 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 60 |
650 | 10 | 5.6 | 60 | 3P | QSI | file link |
| moreQL65F7SA
Wavelength (nm): 650 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 70 |
650 | 10 | 5.6 | 70 | 1N | QSI | file link |
| moreQL65F73A
Wavelength (nm): 650 Power (mW): 10 Package (mm): 3.3 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 70 |
650 | 10 | 3.3 | 70 | 1N | QSI | file link |
| moreQL65F73B
Wavelength (nm): 650 Power (mW): 10 Package (mm): 3.3 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 70 |
650 | 10 | 3.3 | 70 | 2M | QSI | file link |
| moreQL65F7SB
Wavelength (nm): 650 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 70 |
650 | 10 | 5.6 | 70 | 2M | QSI | file link |
| moreQL65F7SC
Wavelength (nm): 650 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 70 |
650 | 10 | 5.6 | 70 | 3P | QSI | file link |
| moreQL65I7SA-H
Wavelength (nm): 650 Power (mW): 30 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 70 |
650 | 30 | 5.6 | 70 | 1N | QSI | file link |
| moreHL65014DG
Wavelength (nm): 650 Power (mW): 150 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 40 |
650 | 150 | 5.6 | 40 | LD Only | Ushio | file link |
| moreTO-656-PLR35
Wavelength (nm): 656 Power (mW): 35 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 1N Max Operating Temp (°C): 50 |
656 | 35 | 5.6 | 50 | 1N | Ondax | file link |
| moreQL65I7SA
Wavelength (nm): 658 Power (mW): 30 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 70 |
658 | 30 | 5.6 | 70 | 1N | QSI | file link |
| moreQL65I7SB
Wavelength (nm): 658 Power (mW): 30 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 70 |
658 | 30 | 5.6 | 70 | 2M | QSI | file link |
| moreQL65I7SC
Wavelength (nm): 658 Power (mW): 30 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 70 |
658 | 30 | 5.6 | 70 | 3P | QSI | file link |
| moreTO-658-PLR35
Wavelength (nm): 658 Power (mW): 35 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 1N Max Operating Temp (°C): 50 |
658 | 35 | 5.6 | 50 | 1N | Ondax | file link |
| moreHL6501MG-A
Wavelength (nm): 658 Power (mW): 35 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 60 |
658 | 35 | 5.6 | 60 | 3P | Ushio | file link |
| moreQL65I7SB-H
Wavelength (nm): 658 Power (mW): 35 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 70 |
658 | 35 | 5.6 | 70 | 2M | QSI | file link |
| moreQL65I7SC-H
Wavelength (nm): 658 Power (mW): 35 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 70 |
658 | 35 | 5.6 | 70 | 3P | QSI | file link |
| moreQL65I7SA-S
Wavelength (nm): 658 Power (mW): 35 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 70 |
658 | 35 | 5.6 | 70 | 1N | QSI | file link |
| moreQL65I7SB-S
Wavelength (nm): 658 Power (mW): 35 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 70 |
658 | 35 | 5.6 | 70 | 2M | QSI | file link |
| moreQL65I7SC-S
Wavelength (nm): 658 Power (mW): 35 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 70 |
658 | 35 | 5.6 | 70 | 3P | QSI | file link |
| moreHL65261MG
Wavelength (nm): 658 Power (mW): 85 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 60 |
658 | 85 | 5.6 | 60 | 3P | Ushio | file link |
| moreHL65213HD
Wavelength (nm): 659 Power (mW): 1200 Package (mm): 9 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 45 |
659 | 1200 | 9 | 45 | LD Only | Ushio | file link |
| moreTO-660-PLR35
Wavelength (nm): 660 Power (mW): 35 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 1N Max Operating Temp (°C): 50 |
660 | 35 | 5.6 | 50 | 1N | Ondax | file link |
| moreQL65J7SA
Wavelength (nm): 660 Power (mW): 50 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 75 |
660 | 50 | 5.6 | 75 | 1N | QSI | file link |
| moreQL65J7SB
Wavelength (nm): 660 Power (mW): 50 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 75 |
660 | 50 | 5.6 | 75 | 2M | QSI | file link |
| moreQL65J7SC
Wavelength (nm): 660 Power (mW): 50 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 75 |
660 | 50 | 5.6 | 75 | 3P | QSI | file link |
| moreHL65241DG
Wavelength (nm): 660 Power (mW): 100 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 90 |
660 | 100 | 5.6 | 90 | 3P | Ushio | file link |
| moreHL65242DG
Wavelength (nm): 660 Power (mW): 100 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 90 |
660 | 100 | 5.6 | 90 | 1N | Ushio | file link |
| moreHL65243DG
Wavelength (nm): 660 Power (mW): 100 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 90 |
660 | 100 | 5.6 | 90 | LD Only | Ushio | file link |
| moreHL65051DG
Wavelength (nm): 660 Power (mW): 120 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 60 |
660 | 120 | 5.6 | 60 | 3P | Ushio | file link |
| moreHL6544FM-A
Wavelength (nm): 660 Power (mW): 130 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 75 |
660 | 130 | 5.6 | 75 | LD Only | Ushio | file link |
| moreHL6545MG-A
Wavelength (nm): 660 Power (mW): 130 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 75 |
660 | 130 | 5.6 | 75 | LD Only | Ushio | file link |
| moreQL67D6SA
Wavelength (nm): 670 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 60 |
670 | 5 | 5.6 | 60 | 1N | QSI | file link |
| moreQL67D6SB
Wavelength (nm): 670 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 60 |
670 | 5 | 5.6 | 60 | 2M | QSI | file link |
| moreQL67D6SC
Wavelength (nm): 670 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 60 |
670 | 5 | 5.6 | 60 | 3P | QSI | file link |
| moreQL67D7SA
Wavelength (nm): 670 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 70 |
670 | 5 | 5.6 | 70 | 1N | QSI | file link |
| moreQL67D7SB
Wavelength (nm): 670 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 70 |
670 | 5 | 5.6 | 70 | 2M | QSI | file link |
| moreQL67D7SC
Wavelength (nm): 670 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 70 |
670 | 5 | 5.6 | 70 | 3P | QSI | file link |
| moreHL6714G-A
Wavelength (nm): 670 Power (mW): 10 Package (mm): 9 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 50 |
670 | 10 | 9 | 50 | 1N | Ushio | file link |
| moreHL6748MG-A
Wavelength (nm): 670 Power (mW): 10 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 60 |
670 | 10 | 5.6 | 60 | 1N | Ushio | file link |
| moreQL67F6SA
Wavelength (nm): 670 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 60 |
670 | 10 | 5.6 | 60 | 1N | QSI | file link |
| moreQL67F6SB
Wavelength (nm): 670 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 60 |
670 | 10 | 5.6 | 60 | 2M | QSI | file link |
| moreQL67F6SC
Wavelength (nm): 670 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 60 |
670 | 10 | 5.6 | 60 | 3P | QSI | file link |
| moreQL67F7SA
Wavelength (nm): 670 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 70 |
670 | 10 | 5.6 | 70 | 1N | QSI | file link |
| moreQL67F7SB
Wavelength (nm): 670 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 70 |
670 | 10 | 5.6 | 70 | 2M | QSI | file link |
| moreQL67F7SC
Wavelength (nm): 670 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 70 |
670 | 10 | 5.6 | 70 | 3P | QSI | file link |
| moreHL6756MG-A
Wavelength (nm): 670 Power (mW): 15 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 60 |
670 | 15 | 5.6 | 60 | 1N | Ushio | file link |
| moreHL67011DG
Wavelength (nm): 671 Power (mW): 210 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3 PIN Max Operating Temp (°C): 75 |
671 | 210 | 5.6 | 75 | 3 PIN | Ushio | file link |
| moreHL67001DG
Wavelength (nm): 675 Power (mW): 210 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 75 |
675 | 210 | 5.6 | 75 | 3P | Ushio | file link |
| moreHL67001DG
Wavelength (nm): 675 Power (mW): 210 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 75 |
675 | 210 | 5.6 | 75 | 3P | Ushio | file link |
| moreHL67203HD
Wavelength (nm): 675 Power (mW): 1300 Package (mm): 9 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 75 |
675 | 1300 | 9 | 75 | LD Only | Ushio | file link |
| moreHL67221DG
Wavelength (nm): 680 Power (mW): 210 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 75 |
680 | 210 | 5.6 | 75 | 3P | Ushio | file link |
| moreQL68I6SA
Wavelength (nm): 685 Power (mW): 30 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 60 |
685 | 30 | 5.6 | 60 | 1N | QSI | file link |
| moreQL68I6SB
Wavelength (nm): 685 Power (mW): 30 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 60 |
685 | 30 | 5.6 | 60 | 2M | QSI | file link |
| moreQL68I6SC
Wavelength (nm): 685 Power (mW): 30 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 60 |
685 | 30 | 5.6 | 60 | 3P | QSI | file link |
| moreTO-685-PLR45-2
Wavelength (nm): 685 Power (mW): 45 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 1N Max Operating Temp (°C): 50 |
685 | 45 | 5.6 | 50 | 1N | Ondax | file link |
| moreQL68J6SA
Wavelength (nm): 685 Power (mW): 50 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 60 |
685 | 50 | 5.6 | 60 | 1N | QSI | file link |
| moreQL68J6SB
Wavelength (nm): 685 Power (mW): 50 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 60 |
685 | 50 | 5.6 | 60 | 2M | QSI | file link |
| moreQL68J6SC
Wavelength (nm): 685 Power (mW): 50 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 60 |
685 | 50 | 5.6 | 60 | 3P | QSI | file link |
| moreHL6750MG-A
Wavelength (nm): 685 Power (mW): 50 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 70 |
685 | 50 | 5.6 | 70 | 3P | Ushio | file link |
| moreTO-687-PLR45-2
Wavelength (nm): 687 Power (mW): 45 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 1N Max Operating Temp (°C): 50 |
687 | 45 | 5.6 | 50 | 1N | Ondax | file link |
| moreTO-689-PLR45
Wavelength (nm): 689 Power (mW): 45 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 3P Max Operating Temp (°C): 50 |
689 | 45 | 5.6 | 50 | 3P | Ondax | file link |
| moreHL6738MG-A
Wavelength (nm): 690 Power (mW): 35 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 70 |
690 | 35 | 5.6 | 70 | 3P | Ushio | file link |
| moreHL69001DG
Wavelength (nm): 690 Power (mW): 210 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 75 |
690 | 210 | 5.6 | 75 | 3P | Ushio | file link |
| moreHL69001DG
Wavelength (nm): 690 Power (mW): 210 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 75 |
690 | 210 | 5.6 | 75 | 3P | Ushio | file link |
| moreHL69203HD
Wavelength (nm): 690 Power (mW): 1300 Package (mm): 9 Manufacturer: Ushio Pin Configuration: LD Only Max Operating Temp (°C): 75 |
690 | 1300 | 9 | 75 | LD Only | Ushio | file link |
| moreTO-691-PLR45
Wavelength (nm): 691 Power (mW): 45 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 3P Max Operating Temp (°C): 50 |
691 | 45 | 5.6 | 50 | 3P | Ondax | file link |
| moreHL70021DG
Wavelength (nm): 700 Power (mW): 210 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 75 |
700 | 210 | 5.6 | 75 | 3P | Ushio | file link |
| moreHL7001MG-A
Wavelength (nm): 705 Power (mW): 50 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 60 |
705 | 50 | 5.6 | 60 | 3P | Ushio | file link |
| moreHL7002MG-A
Wavelength (nm): 705 Power (mW): 50 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 60 |
705 | 50 | 5.6 | 60 | 1N | Ushio | file link |
| moreHL70031DG
Wavelength (nm): 705 Power (mW): 210 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): — |
705 | 210 | 5.6 | — | 3P | Ushio | file link |
| moreHL7301MG-A
Wavelength (nm): 730 Power (mW): 40 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 60 |
730 | 40 | 5.6 | 60 | 3P | Ushio | file link |
| moreHL7302MG-A
Wavelength (nm): 730 Power (mW): 40 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 60 |
730 | 40 | 5.6 | 60 | 1N | Ushio | file link |
| moreQL78D6SA
Wavelength (nm): 780 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 60 |
780 | 5 | 5.6 | 60 | 1N | QSI | file link |
| moreQL78D6SB
Wavelength (nm): 780 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 60 |
780 | 5 | 5.6 | 60 | 2M | QSI | file link |
| moreQL78D6SC
Wavelength (nm): 780 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 60 |
780 | 5 | 5.6 | 60 | 3P | QSI | file link |
| moreQL78F6SA
Wavelength (nm): 780 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 60 |
780 | 10 | 5.6 | 60 | 1N | QSI | file link |
| moreQL78F6SB
Wavelength (nm): 780 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 60 |
780 | 10 | 5.6 | 60 | 2M | QSI | file link |
| moreQL78F6SC
Wavelength (nm): 780 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 60 |
780 | 10 | 5.6 | 60 | 3P | QSI | file link |
| moreQL78F8SA
Wavelength (nm): 780 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 80 |
780 | 10 | 5.6 | 80 | 1N | QSI | file link |
| moreQL78F8SB
Wavelength (nm): 780 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 80 |
780 | 10 | 5.6 | 80 | 1N | QSI | file link |
| moreQL78F8SC
Wavelength (nm): 780 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 80 |
780 | 10 | 5.6 | 80 | 3P | QSI | file link |
| moreQL78I6SA-L
Wavelength (nm): 780 Power (mW): 25 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 60 |
780 | 25 | 5.6 | 60 | 1N | QSI | file link |
| moreQL78I6SB-L
Wavelength (nm): 780 Power (mW): 25 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 60 |
780 | 25 | 5.6 | 60 | 2M | QSI | file link |
| moreQL78I6SC-L
Wavelength (nm): 780 Power (mW): 25 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 60 |
780 | 25 | 5.6 | 60 | 3P | QSI | file link |
| moreQL78I6SA
Wavelength (nm): 780 Power (mW): 30 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 60 |
780 | 30 | 5.6 | 60 | 1N | QSI | file link |
| moreQL78I6SB
Wavelength (nm): 780 Power (mW): 30 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 60 |
780 | 30 | 5.6 | 60 | 2M | QSI | file link |
| moreQL78I6SC
Wavelength (nm): 780 Power (mW): 30 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 60 |
780 | 30 | 5.6 | 60 | 3P | QSI | file link |
| moreQL78J6SA
Wavelength (nm): 780 Power (mW): 50 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 60 |
780 | 50 | 5.6 | 60 | 1N | QSI | file link |
| moreQL78J6SB
Wavelength (nm): 780 Power (mW): 50 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 60 |
780 | 50 | 5.6 | 60 | 2M | QSI | file link |
| moreQL78J6SC
Wavelength (nm): 780 Power (mW): 50 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 60 |
780 | 50 | 5.6 | 60 | 3P | QSI | file link |
| moreQL78K8SA
Wavelength (nm): 780 Power (mW): 60 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 80 |
780 | 60 | 5.6 | 80 | 1N | QSI | file link |
| moreQL78K8SB
Wavelength (nm): 780 Power (mW): 60 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 80 |
780 | 60 | 5.6 | 80 | 2M | QSI | file link |
| moreQL78K8SC
Wavelength (nm): 780 Power (mW): 60 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 80 |
780 | 60 | 5.6 | 80 | 3P | QSI | file link |
| moreTO-780.25-PLR80-T
Wavelength (nm): 780 Power (mW): 80 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: LD Only Max Operating Temp (°C): 40 |
780 | 80 | 5.6 | 40 | LD Only | Ondax | file link |
| moreQL78M8SA
Wavelength (nm): 780 Power (mW): 90 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 80 |
780 | 90 | 5.6 | 80 | 1N | QSI | file link |
| moreQL78M8SB
Wavelength (nm): 780 Power (mW): 90 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 80 |
780 | 90 | 5.6 | 80 | 2M | QSI | file link |
| moreQL78M8SC
Wavelength (nm): 780 Power (mW): 90 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 80 |
780 | 90 | 5.6 | 80 | 3P | QSI | file link |
| moreTO-785-PLR80
Wavelength (nm): 785 Power (mW): 80 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 1N Max Operating Temp (°C): 50 |
785 | 80 | 5.6 | 50 | 1N | Ondax | file link |
| moreTO-785-PLR100
Wavelength (nm): 785 Power (mW): 100 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: LD Only Max Operating Temp (°C): 40 |
785 | 100 | 5.6 | 40 | LD Only | Ondax | file link |
| moreCP-785-PLR500-2
Wavelength (nm): 785 Power (mW): 500 Package (mm): 9 Manufacturer: Ondax Pin Configuration: LD Only Max Operating Temp (°C): 50 |
785 | 500 | 9 | 50 | LD Only | Ondax | file link |
| moreBF-785-PLR600-FC/PC
Wavelength (nm): 785 Power (mW): 600 Package (mm): N/A Manufacturer: Ondax Pin Configuration: N/A Max Operating Temp (°C): 40 |
785 | 600 | N/A | 40 | N/A | Ondax | file link |
| moreTO-787-PLR80
Wavelength (nm): 787 Power (mW): 80 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 1N Max Operating Temp (°C): 50 |
787 | 80 | 5.6 | 50 | 1N | Ondax | file link |
| moreQL80T4HD-Y
Wavelength (nm): 808 Power (mW): 1 Package (mm): 9 Manufacturer: QSI Pin Configuration: LD Only Max Operating Temp (°C): 40 |
808 | 1 | 9 | 40 | LD Only | QSI | file link |
| moreTO-808-PLR170
Wavelength (nm): 808 Power (mW): 170 Package (mm): 5.6 Manufacturer: Ondax Pin Configuration: 1N Max Operating Temp (°C): 50 |
808 | 170 | 5.6 | 50 | 1N | Ondax | file link |
| moreQL80S4HD-Y
Wavelength (nm): 808 Power (mW): 500 Package (mm): 9 Manufacturer: QSI Pin Configuration: LD Only Max Operating Temp (°C): 40 |
808 | 500 | 9 | 40 | LD Only | QSI | file link |
| moreQL83H6SA
Wavelength (nm): 830 Power (mW): 20 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 60 |
830 | 20 | 5.6 | 60 | 1N | QSI | file link |
| moreQL83H6SB
Wavelength (nm): 830 Power (mW): 20 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 60 |
830 | 20 | 5.6 | 60 | 2M | QSI | file link |
| moreQL83H6SC
Wavelength (nm): 830 Power (mW): 20 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 60 |
830 | 20 | 5.6 | 60 | 3P | QSI | file link |
| moreHL8337MG-A
Wavelength (nm): 830 Power (mW): 50 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 60 |
830 | 50 | 5.6 | 60 | 1N | Ushio | file link |
| moreHL8338MG-A
Wavelength (nm): 830 Power (mW): 50 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 60 |
830 | 50 | 5.6 | 60 | 3P | Ushio | file link |
| moreQL83O6SA
Wavelength (nm): 830 Power (mW): 100 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 60 |
830 | 100 | 5.6 | 60 | 1N | QSI | file link |
| moreQL83O6SB
Wavelength (nm): 830 Power (mW): 100 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 60 |
830 | 100 | 5.6 | 60 | 2M | QSI | file link |
| moreQL83O6SC
Wavelength (nm): 830 Power (mW): 100 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 60 |
830 | 100 | 5.6 | 60 | 3P | QSI | file link |
| moreCP-830-PLR500
Wavelength (nm): 830 Power (mW): 500 Package (mm): 9 Manufacturer: Ondax Pin Configuration: LD Only Max Operating Temp (°C): 50 |
830 | 500 | 9 | 50 | LD Only | Ondax | file link |
| moreQL85D6SA
Wavelength (nm): 850 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 60 |
850 | 5 | 5.6 | 60 | 1N | QSI | file link |
| moreQL85D6SB
Wavelength (nm): 850 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 60 |
850 | 5 | 5.6 | 60 | 2M | QSI | file link |
| moreQL85D6SC
Wavelength (nm): 850 Power (mW): 5 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 60 |
850 | 5 | 5.6 | 60 | 3P | QSI | file link |
| moreQL85F6SA
Wavelength (nm): 850 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 60 |
850 | 10 | 5.6 | 60 | 1N | QSI | file link |
| moreQL85F6SB
Wavelength (nm): 850 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 60 |
850 | 10 | 5.6 | 60 | 2M | QSI | file link |
| moreQL85F6SC
Wavelength (nm): 850 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 60 |
850 | 10 | 5.6 | 60 | 3P | QSI | file link |
| moreQL85J6SA-L
Wavelength (nm): 850 Power (mW): 40 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 60 |
850 | 40 | 5.6 | 60 | 1N | QSI | file link |
| moreQL85J6SB-L
Wavelength (nm): 850 Power (mW): 40 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 60 |
850 | 40 | 5.6 | 60 | 2M | QSI | file link |
| moreQL85J6SC-L
Wavelength (nm): 850 Power (mW): 40 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 60 |
850 | 40 | 5.6 | 60 | 3P | QSI | file link |
| moreHL85021MG/022MG/023MG
Wavelength (nm): 850 Power (mW): 260 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 75 |
850 | 260 | 5.6 | 75 | 3P | Ushio | file link |
| moreHL8340MG-A
Wavelength (nm): 852 Power (mW): 50 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 1N Max Operating Temp (°C): 60 |
852 | 50 | 5.6 | 60 | 1N | Ushio | file link |
| moreHL8341MG-A
Wavelength (nm): 852 Power (mW): 50 Package (mm): 5.6 Manufacturer: Ushio Pin Configuration: 3P Max Operating Temp (°C): 60 |
852 | 50 | 5.6 | 60 | 3P | Ushio | file link |
| moreQL90F7SA
Wavelength (nm): 905 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 1N Max Operating Temp (°C): 70 |
905 | 10 | 5.6 | 70 | 1N | QSI | file link |
| moreQL90F7SB
Wavelength (nm): 905 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 2M Max Operating Temp (°C): 70 |
905 | 10 | 5.6 | 70 | 2M | QSI | file link |
| moreQL90F7SC
Wavelength (nm): 905 Power (mW): 10 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: 3P Max Operating Temp (°C): 70 |
905 | 10 | 5.6 | 70 | 3P | QSI | file link |
| moreQL90V8SM
Wavelength (nm): 905 Power (mW): 25000 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: LD Only Max Operating Temp (°C): 85 |
905 | 25000 | 5.6 | 85 | LD Only | QSI | file link |
| moreQL90W8SM
Wavelength (nm): 905 Power (mW): 50000 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: LD Only Max Operating Temp (°C): 85 |
905 | 50000 | 5.6 | 85 | LD Only | QSI | file link |
| moreQL90X8SM
Wavelength (nm): 905 Power (mW): 75000 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: LD Only Max Operating Temp (°C): 85 |
905 | 75000 | 5.6 | 85 | LD Only | QSI | file link |
| moreQL94J6SA/B/C
Wavelength (nm): 940 Power (mW): 50 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: — Max Operating Temp (°C): 60 |
940 | 50 | 5.6 | 60 | — | QSI | file link |
| moreQL94R6SA/B/C
Wavelength (nm): 940 Power (mW): 200 Package (mm): 5.6 Manufacturer: QSI Pin Configuration: — Max Operating Temp (°C): 60 |
940 | 200 | 5.6 | 60 | — | QSI | file link |
There are no exact matches for your search. Please widen your search criteria and search again or contact us for technical support on your specification.
Need help to optimize for your application?
For comprehensive technical support. Talk to us.
Contact UsContact Us
Bernhard Russell
Inside Sales
Andrea Gregorio
Inside Sales
Need a Mechanical Part for your Laser Diode Assembly?
ProPhotonix has in-house CNC machining facilities and can support you further with your laser requirements, supplying components for your laser diode assembly. Benefit from access to our team’s extensive expertise in the manufacture of precision components to the very tight tolerances required for optoelectronic assemblies. Components up to 32mm in diameter can be produced using a wide range of metals and plastics and a number of different surface treatments including anodizing and plating are available. State-of-the-art measurement equipment allows for testing, data capture, and reporting to meet your specific requirements.
With quantities from single-piece prototypes to tens of thousands of production parts, available cost-effectively and at short lead times, enquire about components for your laser assembly today.
25 Years of Laser Diode Expertise
As both a laser diode supplier and integrator for more than 25 years, ProPhotonix has unique expertise to support you in your application.
Laser Diodes Available from Stock
ProPhotonix offers a wide range of laser diodes available from stock for immediate shipping
Expert Technical Support
Providing knowledgeable technical support on laser diode specification to optimize your application as well as advice on other elements of your system
Related Blog Posts
Subscribe For Updates
Stay up to date with relevant product updates, updates on events, whitepaper and case study release notifications and company news.
